| 夾緊力kN |
| 扭矩Nm |
HDL(M)4 |
HDL(M)6 |
| 14 |
4.6 |
6.8 |
| 27 |
9.5 |
11.2 |
| 41 |
14.0 |
14.9 |
| 54 |
18.0 |
19.2 |
| 68 |
22.2 |
25.6 |
| 81 |
26.1 |
30.5 |
| 95 |
|
33.2 |
| 夾緊力kN |
| 液壓MPa |
HDHL(M)4 |
HDHL(M)6 |
| 3.4 |
|
3.9 |
| 6.9 |
3.4 |
7.1 |
| 10.3 |
6.4 |
10.4 |
| 13.8 |
8.5 |
13.9 |
| 17.2 |
11.3 |
17.6 |
| 20.7 |
13.8 |
21.1 |
| 24.1 |
16.5 |
24.4 |
| 27.6 |
18.7 |
28.2 |
| 31.0 |
21.4 |
31.6 |
| 27.6 |
液壓排量 18CC |
|
|
| HDL型四面體鉗底座尺寸參數表 mm(in) |
|
CTHDL(M)44 |
CTHDL(M)64 |
300MM 底座 |
400MM 底座 |
500MM 底座 |
630MM 底座 |
| A |
|
|
300 |
400 |
500 |
630 |
| B |
|
|
25.4 |
31.75 |
31.75 |
38.1 |
| C |
|
|
20 |
50 |
60 |
70 |
| D |
|
|
158.75 |
158.75 |
158.75 |
215.9 |
| E |
|
|
101.6 |
101.6 |
101.6 |
152.4 |
| F |
|
|
– |
158.75 |
203.2 |
254 |
| G |
|
|
– |
317.5 |
406.4 |
508 |
| H |
|
|
127 |
160 |
200 |
250 |
| J |
|
|
254 |
320 |
400 |
500 |
| K |
|
|
M12內六角螺釘 |
M16內六角螺釘 |
M16內六角螺釘 |
M16內六角螺釘 |
| L |
|
|
– |
– |
– |
|
| M |
|
|
15 |
18 |
18 |
18 |
| N |
|
|
40 |
– |
– |
200 |
| O |
|
|
80 |
– |
– |
100 |
| P |
|
|
M12 x 1.75 |
M16 x 2.0 |
M16 x 2.0 |
M16 x 2.0 |
| Q |
|
|
– |
55 |
55 |
– |
| R |
|
|
– |
110 |
110 |
– |
| S |
|
|
– |
75 |
75 |
– |
| T |
|
|
– |
150 |
150 |
– |
| U |
|
|
– |
25 |
25 |
25 |
| V |
449.6 |
570.23 |
|
|
|
|
| W |
425.78 |
548.38 |
|
|
|
|
| X |
415.92 |
533.4 |
|
|
|
|
| Y |
200.03 |
258.88 |
|
|
|
|
| Z |
15 |
19.05 |
|
|
|
|
| AA |
3.05 |
3.95 |
|
|
|
|
| BB |
14.28 |
19.05 |
|
|
|
|
| CC |
11.1 |
15.87 |
|
|
|
|
| DD |
34.92 |
28.58 |
|
|
|
|
| EE |
65.1 |
79.38 |
|
|
|
|
| FF |
9.53 |
9.53 |
|
|
|
|
| GG |
M8 x 1.25 |
M8 x 1.25 |
|
|
|
|
| 重量 |
|
|
|
|
|
|
中心孔定位塊訂貨號：36V2T400-277-2
|
