| 參數(shù)表 mm(in) |
|
標準型 |
反向型 |
液壓型 |
液壓反向省 |
氣動型氣 |
動反向型 |
|
XL6 |
XL6R |
XL6H |
XL6HR |
XL6A |
XL6AR |
| A |
79.38 |
79.38 |
79.38 |
79.38 |
79.38 |
79.38 |
| B |
152.4 |
152.4 |
152.4 |
152.4 |
152.4 |
152.4 |
| C |
568.96 |
568.96 |
568.96 |
568.96 |
568.96 |
568.96 |
| D |
5.29 |
5.29 |
5.29 |
5.29 |
5.29 |
5.29 |
| E |
17.48 |
17.48 |
17.48 |
17.48 |
17.48 |
17.48 |
| F |
37.72 |
37.72 |
37.72 |
37.72 |
37.72 |
37.72 |
| G |
114.3 |
114.3 |
114.3 |
114.3 |
114.3 |
114.3 |
| H |
44.07 |
44.07 |
44.07 |
44.07 |
44.07 |
44.07 |
| J |
18.42 |
18.42 |
18.42 |
18.42 |
18.42 |
18.42 |
| K |
101.6 |
101.6 |
101.6 |
101.6 |
101.6 |
101.6 |
| L |
525.27 |
525.27 |
525.27 |
525.27 |
525.27 |
525.27 |
| M |
23.88 |
23.88 |
23.88 |
23.88 |
23.88 |
23.88 |
| N |
98.43 |
98.43 |
98.43 |
98.43 |
98.43 |
98.43 |
| O |
(1/2-13) |
(1/2-13) |
(1/2-13) |
(1/2-13) |
(1/2-13) |
(1/2-13) |
| P |
139.70 |
139.70 |
139.70 |
139.70 |
139.70 |
139.70 |
| Q |
139.70 |
139.70 |
139.70 |
139.70 |
139.70 |
139.70 |
| R |
127.00 |
127.00 |
127.00 |
127.00 |
127.00 |
127.00 |
| S |
30.18 |
30.18 |
30.18 |
30.18 |
30.18 |
30.18 |
| T |
100.00 |
100.00 |
100.00 |
100.00 |
100.00 |
100.00 |
| U |
127.00 |
127.00 |
127.00 |
127.00 |
127.00 |
127.00 |
| V |
15.88 |
15.88 |
15.88 |
15.88 |
15.88 |
15.88 |
| W |
16.00 |
16.00 |
16.00 |
16.00 |
16.00 |
16.00 |
| X |
11.13 |
11.13 |
11.13 |
11.13 |
11.13 |
11.13 |
| Y |
38.10 |
38.10 |
38.10 |
38.10 |
38.10 |
38.10 |
| Z |
19.05 |
19.05 |
19.05 |
15.88 |
19.05 |
15.88 |
| AA |
368.30 |
368.30 |
368.30 |
368.30 |
368.30 |
368.30 |
| BB |
488.95 |
488.95 |
488.95 |
488.95 |
488.95 |
488.95 |
| CC |
17.53 |
17.53 |
17.53 |
17.53 |
17.53 |
17.53 |
| DD |
37.34 |
37.34 |
37.34 |
37.34 |
37.34 |
37.34 |
| EE |
16.00 |
16.00 |
16.00 |
16.00 |
16.00 |
16.00 |
| FF |
21.59 |
21.59 |
21.59 |
21.59 |
21.59 |
21.59 |
| GG |
20.32 |
20.32 |
20.32 |
20.32 |
20.32 |
20.32 |
| HH |
9.14 |
9.14 |
9.14 |
9.14 |
9.14 |
9.14 |
| JJ |
16.00 |
16.00 |
16.00 |
16.00 |
16.00 |
16.00 |
| KK |
31.75 |
31.75 |
31.75 |
31.75 |
31.75 |
31.75 |
| LL |
- |
- |
63.50 |
63.50 |
- |
- |
| MM |
- |
- |
85.85 |
85.85 |
- |
- |
| NN |
- |
- |
- |
- |
182.88 |
182.88 |
| PP |
- |
- |
- |
- |
25.40 |
25.40 |
| QQ |
- |
- |
- |
- |
127.00 |
127.00 |
| RR |
- |
- |
- |
- |
88.90 |
88.90 |
| SS |
13.49 |
13.49 |
13.49 |
13.49 |
13.49 |
13.49 |
| TT |
101.60 |
101.60 |
101.60 |
101.60 |
101.60 |
101.60 |
| 重量kg |
45.4 |
45.4 |
47.6 |
47.6 |
48.1 |
48.1 |
| 液壓排量CC |
- |
- |
11.3 |
11.3 |
- |
- |
|
|
| 夾緊力kN |
| 手動扭矩Nm |
標準型 |
| XL6 |
XL6R |
| 13.6 |
3.5 |
3.5 |
| 27.1 |
8.0 |
8.0 |
| 40.7 |
11.2 |
11.2 |
| 54.2 |
15.2 |
15.2 |
| 67.8 |
18.7 |
18.7 |
| 81.4 |
22.3 |
22.3 |
| 94.9 |
28.0 |
28.0 |
| 108.5 |
30.6 |
30.6 |
| 夾緊力kN |
| 液壓MPa |
液壓型 |
| XL6H |
XL6HR |
| 2.8 |
4.0 |
4.0 |
| 5.5 |
6.8 |
6.8 |
| 8.3 |
12.2 |
12.2 |
| 11.0 |
16.2 |
16.2 |
| 13.8 |
20.5 |
20.5 |
| 16.6 |
24.5 |
24.5 |
| 19.3 |
28.6 |
28.6 |
| 22.1 |
32.7 |
32.7 |
注：夾緊力僅供參考
| 夾緊力kN |
| 氣壓Bar |
氣動型 |
| XL6A |
XL6AR |
| 0.7 |
1.4 |
1.4 |
| 1.4 |
3.7 |
3.7 |
| 2.1 |
5.7 |
5.7 |
| 2.8 |
7.9 |
7.9 |
| 3.5 |
9.8 |
9.8 |
| 4.1 |
12.1 |
12.1 |
| 4.8 |
14.4 |
14.4 |
| 5.5 |
16.9 |
16.9 |
| 6.2 |
19.5 |
19.5 |
| 6.9 |
22.2 |
22.2 |
|
